Overview

ManageLM backups follow one strict design principle: your data never touches ManageLM infrastructure. Every archive is encrypted on the agent with a per-backup key, uploaded directly from the agent to your S3 bucket, and decrypted only when you — or another agent you pick — restore it.

Pick an S3 provider once in Settings. From then on, backups are just a schedule, a source path, and a retention count. The agent tars, encrypts, streams to S3, and reports back. No data ever flows through the portal.

Supported S3 providers

Provider-agnostic — one set of credentials, any S3-compatible storage. Each provider has a one-click preset that fills in the endpoint URL, and the Test button validates credentials with a HeadBucket before saving.

• OVH Object Storage
• Amazon S3
• Cloudflare R2
• Backblaze B2
• Wasabi
• Scaleway Object Storage
• MinIO (self-hosted)

Secret keys are stored AES-256-GCM encrypted at rest on the portal. Cloudflare R2 is a popular pick for its zero-egress pricing; OVH Object Storage is preferred for EU-based data residency; MinIO fits fully self-hosted deployments.

End-to-end encryption

Every backup has its own 32-byte random master key, stored wrapped server-side. Before each run, the portal pushes the key to the agent over the existing mTLS WebSocket — never over HTTP, never logged.

The agent implementation is pure-Python via oscrypto — no cryptography package, no native build dependencies, works on every distro the agent supports.

Service quiesce for consistent snapshots

Backing up a live database directory usually produces a broken snapshot — the file is captured mid-transaction. ManageLM solves this with a simple service quiesce list: name the services you want stopped before the backup, and the agent:

1. Stops each listed service via systemctl stop (Linux) or net stop (Windows), with a 30-second timeout per service.
2. Runs the tar → encrypt → upload pipeline against a now-consistent filesystem.
3. Restarts every service that was successfully stopped — inside a try / finally so a backup failure (or even the agent being killed mid-run) never leaves services down.

Restore & portability

Backups are portable — they can be restored to the original agent or any other online agent. This is what makes the system useful beyond disaster recovery: it's also a fleet-wide file transfer tool.

• Download decrypted .tar.gz — mints a one-shot Redis token (5 min TTL), then streams the archive through a rolling-window HMAC/decrypt pipeline straight to the browser. Save dialog opens immediately; progress bar fills as the data arrives.
• Restore to any agent — pick a target agent and path. The agent downloads, verifies HMAC before touching disk, strips the top-level directory, and extracts with a path-traversal guard.
• Abort running backups — cancel a stuck upload and reclaim the snapshot slot.
• Detach on delete — when you delete an agent, its backups are not deleted. The agent_id is cleared instead. A Reassign button lets you attach the backup to a replacement agent later.

Schedule & retention

Each backup has its own cadence and retention policy:

FIFO retention — specify how many snapshots to keep (1–90). Older snapshots are rotated out automatically by the cleanup cron. A stalled-backup detector runs every 15 minutes and alerts you when scheduled backups miss their window by more than the configured grace period.
